Maximum Power Pmax (W) |
630 |
635 |
640 |
645 |
650 |
655 |
|
Voltage at Maximum Power (Vmp/V) |
42.0 |
42.3 |
42.6 |
42.9 |
43.2 |
43.5 |
|
Current at Maximum Power (Imp/A) |
15.02 |
15.04 |
15.06 |
15.08 |
15.10 |
15.12 |
|
Open Circuit Voltage (Voc/V) |
50.20 |
50.50 |
50.80 |
51.10 |
51.40 |
51.70 |
|
Short Circuit Current (Isc/A) |
15.94 |
15.96 |
15.98 |
16.00 |
16.02 |
16.04 |
|
Module Efficiency (%) |
23.3 |
23.5 |
23.7 |
23.9 |
24.1 |
24.2 |
|
Power Tolerance |
0~+3% |
Maximum System Voltage |
DC1500V |
|||
|
Maximum Series Fuse Rating |
30A |
Operating Temperature |
-40°C~+70°C |
|||
|
Bifacial Factor |
80±5% |
|||||
|
Maximum Power Pmax (W) |
693 |
699 |
704 |
710 |
715 |
721 |
|
Voltage at Maximum Power (Vmp/V) |
42.0 |
42.3 |
42.6 |
42.9 |
43.2 |
43.5 |
|
Current at Maximum Power (Imp/A) |
16.52 |
16.54 |
16.57 |
16.59 |
16.61 |
16.63 |
|
Open Circuit Voltage (Voc/V) |
50.20 |
50.50 |
50.80 |
51.10 |
51.40 |
51.70 |
|
Short Circuit Current (Isc/A) |
17.54 |
17.56 |
17.58 |
17.60 |
17.62 |
17.64 |
|
Cell Type |
N-type mono-crystalline |
|
Cell Orientation |
132 (6×22) |
|
Dimension |
2382×1134×30 mm |
|
Weight |
32.2 kg |
|
Front Glass |
2.0mm, Anti-reflection Coating |
|
Back Glass |
2.0mm, Heat Strengthened Glass |
|
Frame |
Composite material |
|
Junction Box |
IP68 rated |
|
Output Cables |
4mm², (+):1200mm, (-):1200mm or customize length |
|
Connector Type |
MC4-EVO2A/others |
|
Mechanical Load |
5400Pa (Front side)/2400Pa (Rear side) |
|
Temperature Coefficients of Pmax |
-0.29%/°C |
|
Temperature Coefficients of Voc |
-0.25%/°C |
|
Temperature Coefficients of Isc |
0.045%/°C |
|
Packing Detail |
36 pcs/pallets, 72 pcs/stack, 720 pcs/40'HQ container |
|
Shutdown Output Voltage |
1±0.1V |
|
Output Bypass |
Yes |
|
Rapid Shutdown Time |
≤25 s |
|
Maximum Input Voltage |
60 V |
|
Maximum System Voltage |
1500 V |
|
Communication Method |
PLC |
|
Maximum Communication Distance |
≤450 m |
