Maximum Power Pmax (W) |
455 |
460 |
465 |
470 |
475 |
480 |
|
Voltage at Maximum Power (Vmp/V) |
30.40 |
30.67 |
30.94 |
31.21 |
31.48 |
31.75 |
|
Current at Maximum Power (Imp/A) |
14.97 |
15.00 |
15.03 |
15.06 |
15.09 |
15.12 |
|
Open Circuit Voltage (Voc/V) |
35.98 |
36.15 |
36.32 |
36.49 |
36.66 |
36.83 |
|
Short Circuit Current (Isc/A) |
15.87 |
15.90 |
15.93 |
15.96 |
15.99 |
16.02 |
|
Module Efficiency (%) |
22.8 |
23.0 |
23.3 |
23.5 |
23.8 |
24.0 |
|
Power Tolerance |
0~+3% |
Maximum System Voltage |
DC1500V |
|||
|
Maximum Series Fuse Rating |
30A |
Operating Temperature |
-40°C~+70°C |
|||
|
Bifacial Factor |
80±5% |
|||||
|
Maximum Power Pmax (W) |
501 |
506 |
512 |
517 |
523 |
528 |
|
Voltage at Maximum Power (Vmp/V) |
30.40 |
30.67 |
30.94 |
31.21 |
31.48 |
31.75 |
|
Current at Maximum Power (Imp/A) |
16.47 |
16.50 |
16.53 |
16.57 |
16.60 |
16.63 |
|
Open Circuit Voltage (Voc/V) |
35.98 |
36.15 |
36.32 |
36.49 |
36.66 |
36.83 |
|
Short Circuit Current (Isc/A) |
17.46 |
17.49 |
17.52 |
17.56 |
17.59 |
17.62 |
|
Cell Type |
N-type mono-crystalline |
|
Cell Orientation |
96 (2×48) |
|
Dimension |
1762×1134×30 mm |
|
Weight |
24.0 kg |
|
Front Glass |
2.0mm, Anti-reflection Coating |
|
Back Glass |
2.0mm, Heat Strengthened Glass |
|
Frame |
Anodized aluminum alloy |
|
Junction Box |
IP68 rated |
|
Output Cables |
4mm², (+): 1200mm, (-): 1200mm or customize length |
|
Connector Type |
MC4-EVO2A/others |
|
Mechanical Load |
5400Pa (Front side)/2400Pa (Rear side) |
|
Temperature Coefficients of Pmax |
-0.29%/°C |
|
Temperature Coefficients of Voc |
-0.25%/°C |
|
Temperature Coefficients of Isc |
0.045%/°C |
|
Packing Detail |
36 pcs/pallets, 72 pcs/stack, 936 pcs/40'HQ container |
|
Shutdown Output Voltage |
1±0.1V |
|
Output Bypass |
Yes |
|
Rapid Shutdown Time |
≤25 s |
|
Maximum Input Voltage |
60 V |
|
Maximum System Voltage |
1500 V |
|
Communication Method |
PLC |
|
Maximum Communication Distance |
≤450 m |
