Maximum Power Pmax (W) |
515 |
520 |
525 |
530 |
535 |
540 |
|
Voltage at Maximum Power (Vmp/V) |
34.43 |
34.67 |
34.91 |
35.15 |
35.39 |
35.63 |
|
Current at Maximum Power (Imp/A) |
14.96 |
15.00 |
15.04 |
15.08 |
15.12 |
15.16 |
|
Open Circuit Voltage (Voc/V) |
40.60 |
40.78 |
40.96 |
41.14 |
41.32 |
41.50 |
|
Short Circuit Current (Isc/A) |
15.98 |
16.01 |
16.04 |
16.07 |
16.10 |
16.13 |
|
Module Efficiency (%) |
23.2 |
23.4 |
23.6 |
23.8 |
24.1 |
24.3 |
|
Power Tolerance |
0~+3% |
Maximum System Voltage |
DC1500V |
|||
|
Maximum Series Fuse Rating |
30A |
Operating Temperature |
-40°C~+70°C |
|||
|
Bifacial Factor |
80±5% |
|||||
|
Maximum Power Pmax (W) |
567 |
572 |
578 |
583 |
589 |
594 |
|
Voltage at Maximum Power (Vmp/V) |
34.43 |
34.67 |
34.91 |
35.15 |
35.39 |
35.63 |
|
Current at Maximum Power (Imp/A) |
16.46 |
16.50 |
16.54 |
16.59 |
16.63 |
16.68 |
|
Open Circuit Voltage (Voc/V) |
40.60 |
40.78 |
40.96 |
41.14 |
41.32 |
41.50 |
|
Short Circuit Current (Isc/A) |
17.58 |
17.61 |
17.64 |
17.68 |
17.71 |
17.74 |
|
Cell Type |
N-type mono-crystalline |
|
Cell Orientation |
108 (2×54) |
|
Dimension |
1961×1134×30 mm |
|
Weight |
26.5 kg |
|
Front Glass |
2.0mm, Anti-reflection Coating |
|
Back Glass |
2.0mm, Heat Strengthened Glass |
|
Frame |
Anodized aluminum alloy |
|
Junction Box |
IP68 rated |
|
Output Cables |
4mm², (+):1200mm, (-):1200mm or customize length |
|
Connector Type |
MC4-EVO2A/others |
|
Mechanical Load |
5400Pa (Front side)/2400Pa (Rear side) |
|
Temperature Coefficients of Pmax |
-0.29%/°C |
|
Temperature Coefficients of Voc |
-0.25%/°C |
|
Temperature Coefficients of Isc |
0.045%/°C |
|
Packing Detail |
36 pcs/pallets, 72 pcs/stack, 864 pcs/40'HQ container |
|
Shutdown Output Voltage |
1±0.1V |
|
Output Bypass |
Yes |
|
Rapid Shutdown Time |
≤25 s |
|
Maximum Input Voltage |
60 V |
|
Maximum System Voltage |
1500 V |
|
Communication Method |
PLC |
|
Maximum Communication Distance |
≤450 m |
